Application
Leveling of high-speed way and railway slopes, roads.construction sites and building floors
Main features
Imported bearing (Japan) throttle(ltaly) and safety valves(USA),stableand high efficient performance.
| Category | Unit | HNC-mini | HNC-02/04 | HNC-06 | HNC-08 | HNC-10 |
|---|---|---|---|---|---|---|
| Height | mm | 435 | 530 | 650 | 720 | 730 |
| Width | mm | 442 | 550 | 700 | 900 | 900 |
| Impulse Force | ton | 3 | 4 | 6.5 | 11 | 15 |
| Vibration Frequency | rpm/min | 2000 | 2000 | 2000 | 2200 | 2200 |
| Oil Flow | l/min | 30-60 | 45-85 | 85-105 | 120-170 | 120-170 |
| Operating Pressure | kg/cm² | 100-130 | 100-130 | 100-150 | 150-200 | 150-200 |
| Bottom Measurement | mm | 800×442 | 900×550 | 1160×700 | 1300×900 | 1500×1000 |
| Carrier | ton | 2-4 | 4-10 | 12-16 | 18-24 | 30-40 |
| Weight | kg | 200 | 350-500 | 650-800 | 900-1000 | 1100-1300 |
