Product
Classification
| Category | Bucket Type | Tonnage | Width(inch/mm) | Teeth(pc) | Weight(Kg) | Material & Plates Combinations |
|---|---|---|---|---|---|---|
| HNCS2 | Standard Bucket | 2T | 18"/457mm | 4 | 90 | Q355+NM400 Teeth, adapters, side cutters |
| HNCS5 | Standard Bucket | 5T | 24"/610mm | 5 | 160 | |
| HNCS8 | Standard Bucket | 8T | 30"/762mm | 5 | 260 | |
| HNCS12 | Standard Bucket | 12T | 36"/915mm | 5 | 405 | |
| HNCS15 | Standard Bucket | 15T | 42"/1067mm | 6 | 570 | |
| HNCS20 | Standard Bucket | 20T | 48"/1220mm | 6 | 910 | |
| HNCS25 | Standard Bucket | 25T | 48"/1220mm | 6 | 1130 | |
| HNCS30 | Standard Bucket | 30T | 54"/1372mm | 5 | 1395 | |
| HNCR12 | Rock Bucket | 12T | 30"/762mm | 4 | 388 | Q355/Q460+NM400 Thicker plate and higher quality parts (teeth adapters, side cutters) |
| HNCR15 | Rock Bucket | 15T | 36"/915mm | 5 | 600 | |
| HNCR18 | Rock Bucket | 18T | 42"/1067mm | 5 | 815 | |
| HNCR20 | Rock Bucket | 20T | 48"/1220mm | 5 | 1085 | |
| HNCR25 | Rock Bucket | 25T | 54"/1372mm | 6 | 1407 | |
| HNCR30 | Rock Bucket | 30T | 60"/1524mm | 6 | 1725 | |
| HNCR36 | Rock Bucket | 36T | 60"/1524mm | 6 | 1725 | |
| HNCR49 | Rock Bucket | 49T | 66"/1676mm | 6 | 2370 | |
| HNCE20 | Extreme Duty Rock | 20T | 48"/1220mm | 5 | 1282 | Q355/Q460+NM400/NM500/HARDOX400 Rock teeth, adapters side cutters, wing protectors, side wearing plates, back wearing bars |
| HNCE25 | Extreme Duty Rock | 25T | 54"/1372mm | 6 | 1681 | |
| HNCE30 | Extreme Duty Rock | 30T | 60"/1524mm | 6 | 2122 | |
| HNCE36 | Extreme Duty Rock | 36T | 60"/1524mm | 6 | 2122 | |
| HNCE49 | Extreme Duty Rock | 49T | 60"/1676mm | 6 | 2735 |
