Make buckets much more functional and keep rocks or other objects from dropping.
Main Featurese
1.Easy to install and operate.
2.Custom service available.
3.Fit several buckets. Supportive tool; lower the cost and improve.
| Category | Unit | HNC-00 | HNC-01 | HNC-02 | HNC-04 | HNC-06 | HNC-08 |
|---|---|---|---|---|---|---|---|
| Oil Pressure | bar | 110-140 | 110-140 | 110-140 | 120-160 | 150-170 | 160-180 |
| Operating Flow | lpm | 30-55 | 30-55 | 30-55 | 50-100 | 90-110 | 100-140 |
| Suitable Excavator | ton | 1-2 | 2-4 | 4-6 | 7-10 | 12-16 | 17-23 |
| Length A | mm | 582 | 770 | 915 | 1143 | 1450 | 1780 |
| Width B | mm | 155 | 246 | 349 | 394 | 450 | 510 |
| Base Plate Length | mm | 813 | 1043.5 | 1220.5 | 1404.5 | 1845 | 2166 |
| Weight | kg | 41 | 65 | 110 | 165 | 325 | 520 |
| Overall Dimension | mm | 813×155×229 | 1044×246×322 | 1221×349×354 | 1405×392×466 | 1845×450×580 | 2166×510×657 |
