Drilling Auger

Drilling Auger

Classification: Drilling Auger

Tel: +8615965154461

Tel: +8613791168675 (Lori Wei)

Tel: +8615098597813 (Emily)

Details

model	oil flow		Max Torque		Pressure	Rotary Speed	oil hose	Carrier	Drill Dia
unit	gal./min	l/min	Lbf·ft	N·M	Bar	Rpm	Inch	Ton	mm
HN2000	6-14	23-53	2537	1871	205	40-92	1/2	1-2.5	100-400
HN2500	8-16	30-61	3297	2432	205	40-82	1/2	1.5-3	100-500
HN3000	8-16	30-61	3900	2877	240	40-81	1/2	2-3.5	100-600
HN3500	8-18	30-68	4900	3510	240	32-72	1/2	2.5-4.5	100-750
HN4500	10-20	38-76	5719	4500	240	32-64	1/2	3-5	100-900
HN5000	10-20	38-76	6855	5010	240	29-58	1/2	4.5-7	150-600
HN5500	12-22	45-83	8012	5490	240	28-50	1/2	5-7	150-750
HN6000	12-28	45-106	8338	5590	240	34-80	3/4	6-8	150-900
HN7000	16-32	61-121	9397	6931	240	37-72	3/4	7-10	150-900
HN8000	16-36	61-136	10911	8003	240	29-64	3/4	8-12	150-900
HN10000	18-36	70-136	14612	9910	240	26-45	3/4	10-13	150-900
HN12000	21-37	80-140	16236	11976	240	22-43	1	13-17	150-900
HN15000	21-40	80-151	20399	15012	240	20-39	1	13-17	150-1200
HN20000	21-45	80-170	25812	19039	240	17-34	1	13-20	150-1200
HN25000	24-48	90-180	33825	24949	280	16-30	1	15-23	150-1200

未标题-1_01.jpg 未标题-1_02.jpg 未标题-1_03.jpg
